Showing 129–144 of 153 results
Setting standards of performance and reliability
The new Sonatest RailScan 125+ flaw detector delivers a higher level of nearsurface resolution and penetrating power into a portable and rugged enclosure. It also offers more measuring capabilities than its predecessors for rail applications such as:
Phased Array Ultrasonic Inspection Device.
Our RotoArray phased array inspection device gives you faster, more reliable A, B and C-scan imaging with the portability of a handheld probe and performance that rivals that of a full-immersion C-scan system. Easy to use, flexible and rugged, it is designed to simplify ultrasonic inspections, today and in the future.
Ultrasonic Non-Destructive Testing (NDT) has helped engineers inspect composites and metallic structures across all industries for years. Whether it be traditional aluminium laminates, steel pipelines, pressure vessel shells or today’s more complex carbon fibre-based composites, ultrasonic NDT technology has the ability to inspect these parts and create complete inspection maps showing attachment locations, defects and wall losses. Comprehensive integrity reports can be generated, supported by imaging reports and CSV file exporting, data review is simple and repeatable.
Active with key industry leaders for more than 60 years, Sonatest is proud to present the RSflite linear scanning instrument.
The Sitescan 500s offers the end user an entry level broad band flaw detector with full VGA display, sync and proportional outputs and a 50nS (Spike) 200V Pulser.
Typical applications are Weld Fabrication, Corrosion Detection, Forgings & Castings and general UT inspection.
The Sitescan D-50 offers the end user an entry level broadband flaw detector in the popular and portable casing of the established D-Series; with a full VGA display, a 50nS (Spike) 200V, a Pulser 0.5dB gain resolution and an optional rubber boot.
Typical applications are Weld Fabrication, Corrosion Detection, Forgings & Castings and general UT inspection.
Solid Shaft Machined Testers
Speed up your shaft inspections with our Solid Shaft Machined Testers (SAMT). Designed for integration with the powerful Mentor UT phased array platform, more efficient and reliable A-scans are now possible.
Our Sonagage IV is our premier corrosion thickness gage with a wide thickness range. Similar to our precision thickness gages, Sonagage IV can save and store 2,700 custom setups.
USLT USB: Flexible and accurate spot weld inspection.Field-proven ultrasonic flaw detection now with Windows 10 software and a convenient mobility package.
Krautkramer ultrasonic probes and transducers.
Waygate’s Krautkrämer line of ultrasonic contact transducers are designed to last and are easy to use and, above all, accurate. That translates into superior results for our customers. We offer many different types of touch probes, including single-element straight-beam, two-element straight-beam and angle-beam transducer options.
Krautkramer ultrasonic testing.
Immersion probes are the ideal choice for scanning parts with irregular geometries. Because they are the best method for achieving uniform coupling and reliable, reproducible results, they are frequently used in mechanized or automated testing where water is used.
Large parts can be scanned using probe holders, bubblers or water jets, and beam-focusing probes can be used to improve results.
The T-Gage V series offers the latest technologies that will make inspection easier and each model has been built to perform in the roughest of industry conditions. Come with monochrome displays as standard to enhance the user experience functionality. Simple upgrade options are available throughout the life of your gauge.
V2 (A4) UT CALIBRATION BLOCK (12.5mm THICK) (1.5mm DIA Hole)
Used for testing miniature shear wave probe index, time base, beam angle and gain, the block includes a 50mm radius, a 25mm opposing radius and a 1.5mm diameter through hole. Manufactured in accordance with British Standard BS 2704 block A4, Fig. 4, and AS 2083. 12.5 mm thickness.
Features:
Dimensions: 1.705″ (height) X 2.953″ (length) X 0.492″ (width).
Weight: 0.472 LBS
Material: 1018 STEEL, NICKEL PLATED
Specifications: BS 2704 BLOCK A4 FIGURE 4. & AS 2083
V2 (A4) UT CALIBRATION BLOCK (25mm THICK) (1.5mm DIA Hole)
Used for testing miniature shear wave probe index, time base, beam angle and gain, the block includes a 50mm radius, a 25mm opposing radius and a 1.5mm diameter through hole. Manufactured in accordance with British Standard BS 2704 block A4, Fig. 4, and AS 2083. 25 mm thickness.
Features:
V2 (A4) UT CALIBRATION BLOCK (25mm THICK) (1.5mm DIA Hole)
Used for testing miniature shear wave probe index, time base, beam angle and gain, the block includes a 50mm radius, a 25mm opposing radius and a 1.5mm diameter through hole. Manufactured in accordance with British Standard BS 2704 block A4, Fig. 4, and AS 2083. 25 mm thickness.
Features:
V2 (A4) UT CALIBRATION BLOCK (12.5mm THICK) (1.5mm DIA Hole)
Used for testing miniature shear wave probe index, time base, beam angle and gain, the block includes a 50mm radius, a 25mm opposing radius and a 1.5mm diameter through hole. Manufactured in accordance with British Standard BS 2704 block A4, Fig. 4, and AS 2083. 12.5 mm thickness.
Features:
