DSC UT CALIBRATION BLOCK (IMPERIAL)
The DSC block is used to calibrate the sensitivity and distance of the shear wave on ultrasonic equipment. With a 1.0″ radius and a 3.0″ radius on opposite faces, the block has a slot spaced .484″ from the flat surface, with a 3.0″ radius machined .375″ deep. The block includes a 0掳 reference pattern to check the exit point on the wedge, a 1/8″ diameter through hole spaced 戮” from the flat surface, and 45掳, 60掳 and 70掳 marks to measure the actual refraction angle.
Manufactured in accordance with ASTM E164 and AWS 6.16.1B.
Features
- Dimensions: 2.5″ (H) X 4.0″ (L) X 1.0″ (W)
- Weight: 1.701 LBS
- Material: 304 STAINLESS STEEL
- Specifications: ASTM E 164 FIG. A1.11
-
DSC UT CALIBRATION BLOCK (IMPERIAL)
The DSC block is used to calibrate the sensitivity and distance of the shear wave on ultrasonic equipment. With a 1.0″ radius and a 3.0″ radius on opposite faces, the block has a slot spaced .484″ from the flat surface, with a 3.0″ radius machined .375″ deep. The block includes a 0掳 reference pattern to check the exit point on the wedge, a 1/8″ diameter through hole spaced 戮” from the flat surface, and 45掳, 60掳 and 70掳 marks to measure the actual refraction angle.
Manufactured in accordance with ASTM E164 and AWS 6.16.1B.
Features
- Dimensions: 2.5″ (H) X 4.0″ (L) X 1.0″ (W)
- Weight: 0.597 LBS
- Material: 7075-T6 ALUMINIUM
- Specifications: ASTM E 164 FIG. A1.11
-
DSC UT CALIBRATION BLOCK (METRIC)
The DSC block is used to calibrate the sensitivity and shear wave distance of ultrasonic equipment. With a 25mm radius and 75mm on opposite faces, the block has a slot spaced 12.10mm from the flat surface, with a 75mm radius machined to 9.40mm depth. The block includes a 0掳 reference pattern for checking the exit point on the wedge, a 3.20mm diameter through hole spaced 18.80mm from the flat surface and 45掳, 60掳 and 70掳 marks for measuring the actual refraction angle.
Manufactured in accordance with ASTM E164 and AWS 6.16.1B.
Features
- Dimensions: 2.461″ (H) X 3.937″ (L) X 0.984″ (W)
- Weight: 1,621 LBS
- Material: 304 STAINLESS STEEL
- Specifications: ASTM E 164 FIG. A1.11
-
DSC UT CALIBRATION BLOCK (METRIC)
The DSC block is used to calibrate the sensitivity and shear wave distance of ultrasonic equipment. With a 25mm radius and 75mm on opposite faces, the block has a slot spaced 12.10mm from the flat surface, with a 75mm radius machined to 9.40mm depth. The block includes a 0掳 reference pattern for checking the exit point on the wedge, a 3.20mm diameter through hole spaced 18.80mm from the flat surface and 45掳, 60掳 and 70掳 marks for measuring the actual refraction angle.
Manufactured in accordance with ASTM E164 and AWS 6.16.1B.
Features
- Dimensions: 2.461″ (height) X 3.937″ (length) X 0.984″ (width)
- Weight: 0.569 LBS
- Material: 7075-T6 ALUMINIUM
- Specifications: ASTM E 164 FIG. A1.11
-
Ultrasonic cable (UT) DUAL BNC TO DUAL LEMO-00, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in the USA.
CUSTOM CABLES CAN ALSO BE MANUFACTURED AS PER REQUEST (MINIMUM QTY REQUIRED)
-
Ultrasound cable (UT) DUAL BNC to DUAL LEMO-00 PLUG, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in the USA.
CUSTOM CABLES CAN ALSO BE MANUFACTURED AS PER REQUEST (MINIMUM QTY REQUIRED)
-
Ultrasonic cable (UT) DUAL BNC to DUAL MICRODOT, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in the USA.
CUSTOM CABLES CAN ALSO BE MANUFACTURED AS PER REQUEST (MINIMUM QTY REQUIRED).
-
Ultrasonic cable (UT) DUAL LEMO 00 PLUG to DUAL MICRODOT, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in USA.
-
Ultrasound cable (UT) DUAL LEMO-00 PLUG to DUAL LEMO-1, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in USA.
-
Ultrasonic cable (UT) DUAL LEMO-00 to DUAL LEMO-00, High Tech Supplies brand.
Custom cables can also be manufactured and customized as per request (minimum qty required).
CUSTOM CABLES CAN ALSO BE MANUFACTURED AS PER REQUEST (MINIMUM QTY REQUIRED).
Made in the USA.
-
Ultrasonic cable (UT) DUAL LEMO-00 to DUAL LEMO-00 PLUG, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in the USA.
CUSTOM CABLES CAN ALSO BE MANUFACTURED AS PER REQUEST (MINIMUM QTY REQUIRED).
-
Ultrasonic cable (UT) DUAL LEMO-00 to DUAL LEMO-1, High Tech Supplies brand.
Custom cable manufacturing and customization upon request.
Made in USA.
-
Ultrasound cable (UT) DUAL LEMO-00 to DUAL MICRODOT, High Tech Supplies brand.
Manufacture and customization of cables according to your needs upon request.
Made in USA.
-
CALIBRATION BLOCK IIW TYPE 1 UT (IMPERIAL)
Manufactured in accordance with the International Welding Institute and ASTM E164, the IIW-TYPE 1 block is used for the purposes described below:
Calibration of shear and longitudinal transducers.
Verification of shear wedge exit point and refracted angle.
Verification of resolution and sensitivity.
Features
- Dimensions: 4″ (height) X 12″ (length) X 1″ (width)
- Weight: 11,779 LBS
- Material: 1018 STEEL, NICKEL PLATED
- Specifications: ASTM E 164 FIG. A1.1
-
BLOQUE DE CALIBRACI脫N IIW TIPO 1 UT (IMPERIAL)
Fabricado de acuerdo con el Instituto Internacional de Soldadura y ASTM E164, el bloque IIW-TYPE 1 se utiliza para los fines descritos a continuaci贸n:
- Calibraci贸n de transductores de cizalladura y longitudinales.
- Verificaci贸n del punto de salida de la cu帽a de cizallamiento y del 谩ngulo refractado.
- Comprobaci贸n de la resoluci贸n y la sensibilidad.
Caracter铆sticas
Dimensiones: 4″ (alto) X 12″ (largo) X 1″ (ancho)
Peso: 11.972 LBS
Material: ACERO INOXIDABLE 304
Especificaciones: ASTM E 164 FIG. A1.1
-
CALIBRATION BLOCK IIW TYPE 1 UT (IMPERIAL)
Manufactured in accordance with the International Welding Institute and ASTM E164, the IIW-TYPE 1 block is used for the purposes described below:
- Calibration of shear and longitudinal transducers.
- Verification of shear wedge exit point and refracted angle.
- Verification of resolution and sensitivity.
Features
- Dimensions: 4″ (height) X 12″ (length) X 1″ (width)
- Weight: 4,286 LBS
- Material: 7075-T6 ALUMINIUM
- Specifications: ASTM E 164 FIG. A1.1
